HANUMAN can offer you with our valuable DIN43650A, DIN43650B, DIN43650C series of solenoid valve coil connectors, which normally are divided into such five pin distance types as 18mm, 11mm, 10mm, 9.4mm, and 8mm, contact numbers of 3 pins (2+Ground) and 4 pins (3+Ground), rated voltages of 250 VAC, 380VAC, and 300 VDC, brand logos of SBD and blank, outer housing colors of black, brown, transparent, white, and grey, gasket types of flat and profiled, protection classes of IP65 and IP67, M3 mounting screw lengths of 25mm, 28mm and 30mm.
Specifications
|
Serial No. |
SB204 |
|
Model |
DIN43650B |
|
Pin distance |
11 mm |
|
Contact number |
2+1GND |
|
Protection class |
IP65(IEC60529) |
|
Rated voltage |
250 VAC, 300 VDC |
|
Rated current |
16 A |
|
Contact resistance |
5 mΩ or less |
|
Conductor size |
3×1.5mm2 |
|
Mounting gasket |
Profile NBR, black |
|
Mounting screw |
M3×30 |
Overall Dimension(mm)
