Pneumatic Pulse Valve

Right-angle type of pulse solenoid valve is a kind of compressed air switch in the dust removal blasting system of pulse bag house dust collector. The included angle of outlet and inlet ports is 90 degree. Normally it is controlled by the signal sent from pulse jet controller to blow and deash in bag house and then lets the pressure of dust collector keep in the set range, and further to ensure its working power and efficiency.

Explosion-proof pulse valve are specially designed to use in flammable and explosive environment. For EX1380 EX1381 Ex-proof solenoid coil, we have its export documents, like IEC, CE, UL or others.

1. It is used as power source of dust collector system with good blowing effect.
2. It is applied with advanced techniques and key components are produced by imported materials.
3. Valve body is treated with shot blasting, with good anti corrosion performance.
4. It owns good mechanical performance and service life is more than one million cycles.
