Custom Pneumatic Solenoid Coil Connectors from China Leading Factory

As a reputable China-based manufacturer of machinery, we take pride in offering custom pneumatic solenoid coil connectors that cater to the specific needs of our clients. Our factory in China is equipped with the latest technology and expertise to ensure that every product we supply meets the highest standards of quality and performance.

China Factory-Made Pneumatic Solenoid Coil Connectors: A Guide to High-Performance Connections for Manufacturers

Explore the world of high-performance pneumatic connections with our comprehensive guide on solenoid coil connectors, crafted by a leading China-based factory and manufacturer. Our expertise in this field is evident in the quality and reliability of our products, which are designed to meet the stringent demands of industrial applications. As a manufacturer in China, we are committed to providing you with the knowledge and components necessary for achieving the best in pneumatic system connections.

What is the pneumatic solenoid coil connectors?

Pneumatic solenoid coil connectors is an electrical and pneumatic connection component used to connect pneumatic solenoid valve coils and external control components. It is specially designed to provide power connection for solenoid valve coils in pneumatic systems. It ensures that the solenoid valve can receive and respond to instructions from the control system to achieve automated control of the pneumatic system. Designed to ensure stable and reliable operation of solenoid valves, connectors are an indispensable component in modern industrial automation.

Working principle of pneumatic solenoid coil connectors

The pneumatic solenoid coil connectors provides an electrical connection. When the control system sends an electrical signal to the solenoid valve coil, the coil will generate a magnetic field to attract or release the valve core, thus changing the air flow direction or pressure in the pneumatic pipeline and changing the valve state. , to achieve control of pneumatic actuators. The pneumatic solenoid coil connectors is responsible for transmitting this electrical signal to the coil stably and reliably, ensuring the accuracy and efficiency of the entire control process.

The composition of the pneumatic solenoid coil connectors

pneumatic solenoid coil connectors usually consists of shell, inner core, sealing gasket and mounting screws. The outer shell protects the internal circuit from interference from the external environment, while the inner core is responsible for the transmission of electrical signals. The sealing gasket ensures that the connector can still maintain good sealing performance in harsh environments. The mounting screws are used to fix the connector to the solenoid valve or on the control board.

Types of pneumatic solenoid coil connectorss

There are many types of pneumatic solenoid coil connectorss, which can be divided into different types such as plastic and metal according to the shell material; they can be divided into different levels such as low voltage, medium voltage, and high voltage according to the rated voltage; and they can be divided into different levels such as IP65 and IP67 according to the protection level. , to adapt to the needs of different working environments.

Connection method: can be divided into plug-in connector and screw connector. The plug-in connector has a straight plug-in type that directly plugs into the interface of the solenoid valve coil, and an angle plug-in type with an adjustable angle. screw connector

It is fixed on the solenoid valve coil by rotation, and the connection is firm and not easy to fall off.

Protection level: IP65-rated connectors have good dust-proof and waterproof performance and are suitable for harsh environments such as humid and dusty environments. Connectors with higher protection levels, such as IP67, provide higher dust-proof and waterproof protection and are suitable for harsher industrial environments.

Voltage level: It can be divided into low-voltage connectors, medium-voltage connectors, and high-voltage connectors. High-voltage connectors are suitable for high-voltage environments and are usually used in special industrial applications.

Special functions: The explosion-proof connector is suitable for flammable and explosive environments, the quick connect/disconnect connector facilitates quick connection and disconnection of the solenoid valve coil, and the connector with indicator light has an indicator light function that can visually display the working status of the solenoid valve coil. .

Function of pneumatic solenoid coil connectors

Electrical connection and signal transmission: The main function of the pneumatic solenoid coil connectors is to realize the electrical connection between the solenoid valve coil and the control circuit. Through the connector, the control circuit can send electrical signals to the solenoid valve coil to control the opening and closing of the solenoid valve.

Ensure system stability and reliability: pneumatic solenoid coil connectorss are usually made of high-quality materials with good durability and corrosion resistance. This ensures that the connector maintains a good electrical connection in harsh industrial environments.

Simplified Installation and Maintenance: Using pneumatic solenoid coil connectorss can greatly simplify the solenoid valve installation and maintenance process. The connector allows the solenoid valve coil to be easily connected and disconnected without complex welding or wiring operations. This not only saves installation time and reduces manual intervention costs, but also facilitates subsequent maintenance and replacement work.

Why Choose GXR pneumatic solenoid coil connectors

The GXR manufacturer has nearly 30 years of experience in manufacturing pneumatic and hydraulic products in China. Its pneumatic solenoid coil connectorss not only have a wide range of types, but also fully comply with international industrial standards and have good compatibility and replaceability. The factory adopts advanced production technology and strict quality control system to ensure that each connector reaches the industry-leading level. In addition, exclusive pneumatic solenoid coil connectors solutions can be customized according to customer needs.
